HST HM201-I – Addressable Input Monitoring Module
• The HST HM201-I is an addressable input module designed to monitor signals from external devices within fire alarm systems
• Enables integration of third-party systems such as suppression systems, manual call points, and external sensors
• Supports both dry contact and wet contact inputs for flexible connectivity
• Provides real-time status monitoring and instant signal transmission to the fire alarm control panel
• Ideal for expanding system capabilities and enhancing overall safety integration
Technical Specifications:
• Type: Addressable Input Module
• Model: HM201-I
• Operating Voltage: 15 ~ 28 VDC
• Standby Current: ≤ 1 mA @ 24 VDC
• Alarm Current (Max): ≤ 5 mA @ 24 VDC (with LED)
• Input Type: Dry Contact / Wet Contact
• Operating Temperature: -10°C ~ 50°C
• Operating Humidity: ≤ 95% RH (Non-condensing)
• Communication: Compatible with HST Addressable Systems
Key Features:
• External Device Signal Monitoring
• Supports Dry & Wet Contact Inputs
• Addressable System Integration
• Dual LED Indicators (360° Visibility)
• Compact & Space-Saving Design
• Easy Address Programming (Auto / Manual)
• High Reliability & Stable Performance
Applications:
• Fire Suppression System Monitoring
• Third-Party Fire Devices Integration
• External Alarm Signal Monitoring
• Industrial Safety Systems
• Building Automation Integration
• Addressable Fire Alarm Systems
