D-Link DMC-1910T – 10/100BASE-TX to 100BASE-FX SC Single-Mode Media Converter, 15km Fiber Distance, Metal Housing & DMC-1000 Chassis Support

• The D-Link DMC-1910T is a 10/100 to 100BASE-FX SC Single-Mode Media Converter designed to convert 10/100Mbps Fast Ethernet twisted-pair signals into 100BASE-FX single-mode fiber signals.

• It supports single-mode fiber transmission up to 15km, making it suitable for extending Ethernet networks where copper cabling distance is not enough.

• The converter provides 1 RJ45 twisted-pair port and 1 SC fiber port, allowing point-to-point fiber network extension.

• It comes with solid metal case housing, LED status indicators, and an external AC power adapter for standalone installation.

• The DMC-1910T can also be installed inside the DMC-1000 chassis, where the chassis power supply is used instead of the external adapter, and the converter becomes hot-swappable.

• 10/100Mbps Ethernet to 100BASE-FX conversion

• SC single-mode fiber interface

• Fiber distance up to 15km

• 1 RJ45 twisted-pair port

• 1 SC fiber port

• Solid metal housing

• LED status indicators

• External AC power adapter

• Standalone operation support

• DMC-1000 chassis installation support

• Hot-swappable when used with chassis

• Suitable for long-distance Fast Ethernet extension

• Designed for single-mode fiber networks

• Brand: D-Link

• Model: DMC-1910T

• Product Type: 10/100BASE-TX to 100BASE-FX SC Single-Mode Media Converter

• Conversion Type: Fast Ethernet Copper to Fast Ethernet Fiber

• Fiber Type: Single-Mode Fiber

• Fiber Connector: SC

• Maximum Fiber Distance: 15km

• Installation: Standalone / Chassis Installation

• Compatible Chassis: DMC-1000

• Application: Ethernet to Fiber Conversion, Long-Distance Fiber Extension, Point-to-Point Fiber Links

• Copper Port: 1 × RJ45 Twisted-Pair Port

• Fiber Port: 1 × 100BASE-FX SC Fiber Port

• Copper Speed: 10/100Mbps

• Fiber Standard: 100BASE-FX

• Fiber Mode: Single-Mode

• Power: Supported

• 100Mbps Speed: For Twisted-Pair Port

• Full Duplex / Collision: For Twisted-Pair and Fiber Ports

• LINK / ACT: For Twisted-Pair Port

• Power Input: 7.5V / 1.5A

• Power Source: External AC Power Adapter

• Chassis Power: Uses DMC-1000 Chassis Power Supply When Installed Inside Chassis

• Housing: Solid Metal Case

• Dimensions: 120 × 88 × 25mm

• Operating Temperature: 0°C to 40°C

• Storage Temperature: -25°C to 70°C

• Operating Humidity: 10% to 90% Non-Condensing

• EMI: FCC Class B, VCCI Class B, CE Class B, C-Tick

• Fast Ethernet to fiber conversion

• Single-mode fiber network extension

• Long-distance office network links

• Building-to-building fiber connections

• Switch-to-switch fiber uplink

• CCTV and data network fiber backbone

• Telecom and network cabinet installation

• Chassis-based media converter deployment

• Point-to-point fiber connectivity

• Connect Gates recommends the D-Link DMC-1910T for projects that need Fast Ethernet to single-mode fiber conversion up to 15km.

• It is suitable for office networks, CCTV fiber backbones, and building-to-building links where a simple and reliable SC single-mode media converter is required.

• The metal housing, SC fiber interface, standalone operation, and DMC-1000 chassis support make it practical for professional network installations.

• For proper installation, Connect Gates recommends checking the required fiber distance, fiber type, SC connector compatibility, chassis requirement, and power location before deployment.
