D-Link DIR-842 – AC1200 Dual Band Wi-Fi Gigabit Router with 4 Gigabit LAN Ports, Gigabit WAN, QoS, Guest Zone & IPv6 Ready
Overview:
• The D-Link DIR-842 is an AC1200 Wi-Fi Gigabit Router designed for Small Office / Home Office environments.
• It combines high-speed 802.11ac wireless technology, concurrent dual-band Wi-Fi, Gigabit Ethernet ports, and advanced security features in one reliable router.
• The router provides wireless speeds up to 1200Mbps, making it suitable for HD streaming, internet voice calls, online gaming, web browsing, and everyday business connectivity.
• Dual-band Wi-Fi allows users to browse and make internet calls on the 2.4GHz band while streaming media and handling high-bandwidth applications on the 5GHz band.
• Four Gigabit LAN ports provide fast wired connectivity for NAS devices, media centers, gaming consoles, PCs, switches, and other network devices.
• The built-in QoS engine helps prioritize important traffic for smoother application performance.
• The router also supports Guest Zone, WPA/WPA2 security, WPS, NAT firewall, DMZ, web setup wizard, and IPv6 Ready support.
Key Features:
• AC1200 Wi-Fi Gigabit Router
• IEEE 802.11ac Wireless Technology
• Concurrent Dual-Band Wi-Fi
• Wireless Speed up to 1200Mbps
• 2.4GHz and 5GHz Wireless Bands
• 1 × 10/100/1000 Gigabit Ethernet WAN Port
• 4 × 10/100/1000 Gigabit Ethernet LAN Ports
• Four External Antennas
• QoS Engine for Traffic Prioritization
• Guest Zone Support
• WPA / WPA2 Wireless Security
• WPS Wi-Fi Protected Setup
• NAT Firewall Protection
• DMZ Support
• IPv6 Ready
• Web Browser-Based Setup and Configuration
• Setup Wizard for Easy Installation
• Access Control Options
• Suitable for HD Streaming, VoIP, Online Gaming and SOHO Networking
Technical Specifications:
• Product Type: AC1200 Wi-Fi Gigabit Router
• Brand: D-Link
• Model: DIR-842
• Wireless Standard: IEEE 802.11ac/n/g/b/a
• Wireless Class: AC1200
• Wireless Bands: Dual Band 2.4GHz & 5GHz
• Maximum Wireless Speed: Up to 1200Mbps
• WAN Port: 1 × 10/100/1000 Gigabit Ethernet WAN Port
• LAN Ports: 4 × 10/100/1000 Gigabit Ethernet LAN Ports
• Antenna Type: Four External Antennas
• Operating Frequency 2.4GHz: 2400 – 2483.5MHz
• Operating Frequency 5GHz: 5150 – 5725MHz
• Standards: IEEE 802.11ac, 802.11n, 802.11g, 802.11b, 802.11a, 802.3ab, 802.3u
• Security: WPA, WPA2, WPS
• Advanced Features: Web Setup Wizard, QoS, DMZ, NAT Firewall, Guest Zone, IPv6 Ready
• LED Indicators: Power, Internet, WLAN, LAN × 4, WPS
• Minimum OS Requirements: Windows 8 / 7 / Vista or Mac OS X 10.6 or Higher
• Browser Support: Internet Explorer 9, Firefox 20.0, Chrome 25.0, Safari 5.1 or Other Java-Enabled Browser
• Additional Requirement: Cable / DSL Modem or ISP Equipment with Ethernet Port
• Dimensions: 190 × 133 × 38 mm
• Weight: 239g
• Power Adapter Input: 100–240V AC, 50/60Hz
• Power Adapter Output: 12V / 1A
• Operating Temperature: 0°C to 40°C
• Storage Temperature: -20°C to 65°C
• Operating Humidity: 10% to 90% Non-Condensing
• Storage Humidity: 5% to 95% Non-Condensing
• Certifications: NCC, RoHS, BSMI, FCC, D-Link Green
Applications:
• Home Wi-Fi network
• Small office wireless network
• HD video streaming
• Internet voice calls
• Online gaming
• Web browsing and daily internet use
• Wired connection for NAS and media centers
• Gigabit connection for PCs and gaming consoles
• Guest Wi-Fi network setup
• SOHO network security and access control
Connect Gates Recommendation:
• Recommended for home and small office users who need a reliable AC1200 dual-band router with Gigabit wired ports, secure Wi-Fi, QoS and easy setup.
• Suitable for users who need better performance than basic N routers, especially for streaming, gaming, VoIP and multiple connected devices.
