D-Link DGS-1210-52MP – 48-Port Gigabit PoE Smart Managed Switch with 4 × Combo Ports, 370W PoE Budget, VLAN, Surveillance Mode & Static Routing
Overview:
• The D-Link DGS-1210-52MP is a 48-Port Gigabit PoE Smart Managed Switch designed for business networks, IP surveillance systems, wireless access points, VoIP phones, and enterprise LAN expansion.
• It provides 48 × 10/100/1000BASE-T PoE ports and 4 × 100/1000 Mbps combo ports, offering high port density with flexible uplink connectivity.
• The switch supports IEEE 802.3af/at PoE with a total 370W PoE power budget, allowing multiple PoE devices to be powered directly through Ethernet cables.
• It includes advanced features such as VLAN, QoS, IGMP Snooping, STP/RSTP/MSTP, Link Aggregation, Static Routing, Auto Voice VLAN, and Surveillance Mode.
• Management is available through Web GUI, D-Link Network Assistant, Compact CLI, and SNMP, with IPv4/IPv6 Dual Stack, Dual Image, and Dual Configuration support.
Key Features:
• 48 Gigabit PoE ports
• 4 × 100/1000 Mbps combo ports
• Smart managed switch
• IEEE 802.3af/at PoE support
• 370W PoE power budget
• Auto Surveillance VLAN
• Auto Voice VLAN
• Static routing support
• 802.1Q VLAN support
• QoS support
• IGMP Snooping support
• Spanning Tree Protocol support
• Link Aggregation support
• Access Control Lists
• D-Link Safeguard Engine
• ARP Spoofing Prevention
• Smart Binding
• DHCP Snooping
• Web GUI management
• D-Link Network Assistant utility
• Compact CLI through Telnet
• SNMP v1/v2c/v3 support
• IPv6 ready
• Dual software images
• Dual configuration files
Technical Specifications:
General:
• Brand: D-Link
• Model: DGS-1210-52MP
• Product Type: Smart Managed Gigabit PoE Switch
• Series: DGS-1210 Series
• Hardware Version: F1
• Interfaces: 48 × 10/100/1000BASE-T PoE Ports + 4 × 100/1000 Mbps Combo Ports
• Application: CCTV Networks, Business LAN, Access Points, VoIP Phones, PoE Devices, Enterprise Network Expansion
Port Standards:
• Ethernet Standard: IEEE 802.3 10BASE-T Ethernet
• Fast Ethernet Standard: IEEE 802.3u 100BASE-TX Fast Ethernet
• Fiber Standard: IEEE 802.3u 100BASE-FX / IEEE 802.3z 1000BASE-X
• Gigabit Ethernet Standard: IEEE 802.3ab 1000BASE-T
• Energy Efficient Ethernet: IEEE 802.3az
• Flow Control: IEEE 802.3x
• PoE Standard: IEEE 802.3af/at Compliance for PoE Ports
• Network Cables: UTP Cat.5, Cat.5e, Cat.6 up to 100m
• Duplex Mode: Full/Half-Duplex for 10/100 Mbps, Full-Duplex for 1000 Mbps
• Auto MDI/MDIX: Supported
Performance:
• Switching Capacity: 104Gbps
• Forwarding Rate: 77.4Mpps
• Transmission Method: Store-and-Forward
• MAC Address Table: 8K Entries
• Static MAC Addresses: 256 Entries
• Packet Buffer Memory: 12Mbits
• CPU Memory: DDR3 128MB
• Flash Memory: 32MB
PoE Specifications:
• PoE Capable Ports: Ports 1 to 48
• PoE Power Budget: 370W
• PoE Standard: IEEE 802.3af/at
• Time-Based PoE: Supported
• PWR Max LED: Supported
Physical and Environmental:
• Power Input: 100 to 240VAC, 50/60Hz Internal Universal Power Supply
• Maximum Power Consumption PoE Enabled: 478.9W @100V / 454.1W @240V
• Maximum Power Consumption PoE Disabled: 54W @100V / 54.4W @240V
• Standby Power Consumption: 32W @100V / 31.6W @240V
• Acoustics: High Speed 52.4dB(A), Low Speed 47.6dB(A)
• Heat Dissipation: 1634.01BTU/hr @100V / 1549.29BTU/hr @240V
• Fans: 3
• Operating Temperature: -5°C to 50°C
• Storage Temperature: -20°C to 70°C
• Operating Humidity: 0% to 95% Relative Humidity
• Storage Humidity: 0% to 95% Relative Humidity
• Dimensions: 440 × 430 × 44mm
• Weight: 6.26kg
• MTBF: 236,406 Hours
• Certifications: CE Class A, VCCI Class A, FCC Class A, BSMI, CCC
• Safety: CB, UL, BSMI, CCC
Layer 2 Features:
• MAC Address Table: 8K Entries
• IGMP Snooping: IGMP v1/v2, IGMP v3 Awareness
• IGMP Groups: Up to 256 Groups
• Static Multicast Addresses: At least 64
• IGMP Per VLAN: Supported
• IGMP Snooping Querier: Supported
• Loopback Detection: Supported
• Link Aggregation: Maximum 8 Groups, 8 Ports per Group
• LLDP / LLDP-MED: Supported
• Jumbo Frame: Up to 10,000 Bytes
• Spanning Tree: STP, RSTP, MSTP
• Flow Control: IEEE 802.3x Flow Control
• HOL Blocking Prevention: Supported
• Port Mirroring: One-to-One, Many-to-One, Tx/Rx/Both
• MLD Snooping: v1/v2, 256 Groups
VLAN and QoS:
• VLAN: 802.1Q
• Static VLAN Groups: Max. 256
• VID Range: 1 to 4094
• Asymmetric VLAN: Supported
• Auto Voice VLAN: Supported
• Auto Surveillance VLAN: Supported
• QoS: IEEE 802.1p
• Queues: 8 Queues per Port
• Queue Handling: Strict, Weighted Round Robin
• Bandwidth Control: Port-Based Ingress / Egress
• QoS Classification: 802.1p, DSCP, MAC Address, EtherType, IP Address, Protocol Type, ToS, IP Preference, IPv6 Traffic Class, TCP/UDP Port
Layer 3 Features:
• IP Interface: Supported
• Interfaces Supported: 4
• IPv6 Neighbor Discovery: Supported
• Static Routing: Supported
• IPv4 Static Routes: 124 Entries
• IPv6 Static Routes: 50 Entries
Security Features:
• ACL: Max. 50 Access Lists, 768 Rules
• D-Link Safeguard Engine: Supported
• Broadcast / Multicast / Unicast Storm Control: Supported
• Traffic Segmentation: Supported
• SSH v2: Supported
• TLS v1.0: Supported
• DoS Attack Prevention: Supported
• 802.1X Port-Based Access Control: Supported
• Port Security: Up to 64 MAC Addresses per Port
• ARP Spoofing Prevention: Supported
• DHCP Server Screening: Supported
• IP-MAC-Port Binding: Smart Binding Supported
• ARP Inspection: Supported
• DHCP Snooping: Supported
Management Features:
• Web-Based GUI: Supported
• D-Link Network Assistant Utility: Supported
• Compact CLI: Supported
• Telnet Server: Supported
• TFTP Client: Supported
• SNMP: v1/v2c/v3
• SNMP Trap: Supported
• Firmware Backup / Upgrade: Supported
• Smart Wizard: Supported
• Configuration Upload / Download: Supported
• BootP / DHCP Client: Supported
• System Log: Max. 500 Entries
• IPv4 / IPv6 Dual Stack: Supported
• DHCP Auto Configuration: Supported
• RMONv1: Supported
• Trusted Host: Supported
• Dual Image: Supported
• Dual Configuration: Supported
• Cable Diagnostics: Supported
• Factory Reset: Supported
Applications:
• Large IP camera systems
• CCTV PoE networks
• Enterprise LAN infrastructure
• Wireless access point deployment
• VoIP phone systems
• High-density PoE switching
• VLAN-based network segmentation
• Surveillance and data network integration
• Business network expansion
• Managed PoE access layer switching
Connect Gates Recommendation:
• Connect Gates recommends the D-Link DGS-1210-52MP for large CCTV and business network projects that require 48 Gigabit PoE ports with smart management features.
• It is suitable for powering multiple IP cameras, wireless access points, and VoIP phones while managing traffic using VLAN, QoS, and Surveillance Mode.
• The 370W PoE budget, 104Gbps switching capacity, and 4 combo uplink ports make it suitable for high-density PoE installations.
• For proper installation, Connect Gates recommends checking the total PoE load, camera/access point power requirements, uplink design, VLAN plan, rack ventilation, and network management requirements before deployment.
