D-Link DGS-1210-10P – 8-Port Gigabit PoE Smart Managed Switch with 2 × SFP Ports, 65W PoE Budget, VLAN, Surveillance Mode & Static Routing
Overview:
• The D-Link DGS-1210-10P is a Smart Managed Gigabit PoE Switch designed for business networks, CCTV systems, IP cameras, wireless access points, and VoIP phones.
• It provides 8 × 10/100/1000BASE-T PoE ports and 2 × 100/1000 Mbps SFP ports for flexible fiber uplink connectivity.
• The switch supports IEEE 802.3af/at PoE, with a total 65W PoE power budget, allowing network devices to be powered directly through Ethernet cables.
• It includes advanced features such as VLAN, QoS, IGMP Snooping, STP/RSTP/MSTP, Link Aggregation, Static Routing, Auto Voice VLAN, and Surveillance Mode.
• Management is available through Web GUI, D-Link Network Assistant, Compact CLI, SNMP, and supports IPv4/IPv6 Dual Stack, Dual Image, and Dual Configuration.
Key Features:
• 8 Gigabit PoE ports
• 2 × 100/1000 Mbps SFP ports
• Smart managed switch
• IEEE 802.3af/at PoE support
• 65W PoE power budget
• Fanless operation
• Auto Surveillance VLAN
• Auto Voice VLAN
• Static routing support
• 802.1Q VLAN support
• QoS support
• IGMP Snooping support
• Spanning Tree Protocol support
• Link Aggregation support
• Access Control Lists
• D-Link Safeguard Engine
• ARP Spoofing Prevention
• DHCP Snooping
• Web GUI management
• D-Link Network Assistant utility
• Compact CLI through Telnet
• SNMP v1/v2c/v3 support
• IPv6 ready
• Dual software images
• Dual configuration files
Technical Specifications:
General:
• Brand: D-Link
• Model: DGS-1210-10P
• Product Type: Smart Managed Gigabit PoE Switch
• Series: DGS-1210 Series
• Hardware Version: F1
• Interfaces: 8 × 10/100/1000BASE-T PoE Ports + 2 × 100/1000 Mbps SFP Ports
• Power Input: 54.0V DC External Power Adapter
• Application: CCTV Networks, Business LAN, Access Points, VoIP Phones, PoE Devices
Port Standards:
• Ethernet Standard: IEEE 802.3 10BASE-T
• Fast Ethernet Standard: IEEE 802.3u 100BASE-TX
• Fiber Standard: IEEE 802.3u 100BASE-FX / IEEE 802.3z 1000BASE-X
• Gigabit Ethernet Standard: IEEE 802.3ab 1000BASE-T
• Energy Efficient Ethernet: IEEE 802.3az
• Flow Control: IEEE 802.3x
• PoE Standard: IEEE 802.3af/at Compliance for PoE Ports
• Network Cables: UTP Cat.5, Cat.5e, Cat.6 up to 100m
• Duplex Mode: Full/Half-Duplex for 10/100 Mbps, Full-Duplex for 1000 Mbps
• Auto MDI/MDIX: Supported
Performance:
• Switching Capacity: 20Gbps
• Forwarding Rate: 14.88Mpps
• MAC Address Table: 8K Entries
• Static MAC Addresses: 256 Entries
• Packet Buffer Memory: 4.1Mbits
• CPU Memory: DDR3 128MB
• Flash Memory: 32MB
• Transmission Method: Store-and-Forward
PoE Specifications:
• PoE Capable Ports: Ports 1 to 8
• PoE Power Budget: 65W
• PoE Standard: IEEE 802.3af/at
• Time-Based PoE: Supported
• PWR Max LED: Supported
Physical and Environmental:
• Maximum Power Consumption PoE Enabled: 81.9W @100V / 80.6W @240V
• Maximum Power Consumption PoE Disabled: 7.6W @100V / 7.5W @240V
• Standby Power Consumption: 2.5W @100V / 2.5W @240V
• Acoustics: 0dB(A)
• Fans: N/A
• Heat Dissipation: 279.59BTU/hr @100V / 275.04BTU/hr @240V
• Operating Temperature: -5°C to 50°C
• Storage Temperature: -20°C to 70°C
• Operating Humidity: 0% to 95% Relative Humidity
• Storage Humidity: 0% to 95% Relative Humidity
• Dimensions: 280 × 126 × 44mm
• Weight: 0.95kg
• MTBF: 729,258 Hours
• Certifications: CE Class A, VCCI Class A, FCC Class A, BSMI, CCC
• Safety: CB, UL, BSMI, CCC
Layer 2 Features:
• Flow Control: IEEE 802.3x Flow Control
• HOL Blocking Prevention: Supported
• Jumbo Frame: Up to 10,000 Bytes
• IGMP Snooping: IGMP v1/v2, IGMP v3 Awareness
• IGMP Groups: Up to 256 Groups
• IGMP Snooping Querier: Supported
• Loopback Detection: Supported
• Link Aggregation: Maximum 8 Groups, 8 Ports per Group
• LLDP / LLDP-MED: Supported
• Spanning Tree: STP, RSTP, MSTP
• Port Mirroring: One-to-One, Many-to-One, Tx/Rx/Both
• MLD Snooping: v1/v2, 256 Groups
VLAN and QoS:
• VLAN: 802.1Q
• Static VLAN Groups: Max. 256
• VID Range: 1 to 4094
• Asymmetric VLAN: Supported
• Auto Voice VLAN: Supported
• Auto Surveillance VLAN: Supported
• QoS: IEEE 802.1p
• Queues: 8 Queues per Port
• Queue Handling: Strict, Weighted Round Robin
• Bandwidth Control: Port-Based Ingress / Egress
Layer 3 Features:
• IP Interface: Supported
• Interfaces Supported: 4
• IPv6 Neighbor Discovery: Supported
• Static Routing: Supported
• IPv4 Static Routes: 124 Entries
• IPv6 Static Routes: 50 Entries
Security Features:
• ACL: Max. 50 Access Lists, 768 Rules
• D-Link Safeguard Engine: Supported
• Broadcast / Multicast / Unicast Storm Control: Supported
• Traffic Segmentation: Supported
• SSH v2: Supported
• TLS v1.0: Supported
• DoS Attack Prevention: Supported
• 802.1X Port-Based Access Control: Supported
• Port Security: Up to 64 MAC Addresses per Port
• ARP Spoofing Prevention: Supported
• DHCP Server Screening: Supported
• IP-MAC-Port Binding: Supported
• ARP Inspection: Supported
• DHCP Snooping: Supported
Management Features:
• Web-Based GUI: Supported
• D-Link Network Assistant Utility: Supported
• Compact CLI: Supported
• Telnet Server: Supported
• TFTP Client: Supported
• SNMP: v1/v2c/v3
• SNMP Trap: Supported
• Firmware Backup / Upgrade: Supported
• Smart Wizard: Supported
• Configuration Upload / Download: Supported
• BootP / DHCP Client: Supported
• System Log: Max. 500 Entries
• IPv4 / IPv6 Dual Stack: Supported
• DHCP Auto Configuration: Supported
• RMONv1: Supported
• Trusted Host: Supported
• Dual Image: Supported
• Dual Configuration: Supported
• Cable Diagnostics: Supported
• Factory Reset: Supported
Applications:
• Small and medium business networks
• IP camera systems
• CCTV PoE networks
• Wireless access point deployment
• VoIP phone systems
• Fiber uplink connections
• VLAN-based network segmentation
• Surveillance and data network integration
• Quiet office and cabinet installations
Connect Gates Recommendation:
• Connect Gates recommends the D-Link DGS-1210-10P for small and medium CCTV and business network projects that require a compact 8-port PoE smart managed switch with SFP uplinks.
• It is suitable for powering IP cameras, access points, and VoIP phones, while keeping network traffic organized using VLAN, QoS, and Surveillance Mode.
• The fanless 0dB design makes it suitable for offices, small cabinets, and quiet installation areas.
• For proper installation, Connect Gates recommends checking the total PoE load, camera/access point power requirements, SFP uplink design, VLAN plan, and network management requirements before deployment.
