D-Link DAP-F2300W – Wireless N300 2.4GHz In-Wall Indoor Access Point with 2×2 MIMO, PoE, Internal Antenna & Multiple Operation Modes

• The D-Link DAP-F2300W is a mini indoor wireless access point designed for 802.11n 2.4GHz wireless network coverage.

• It provides stable indoor wireless signal coverage for hotels, offices, schools, cafes, shops, and other indoor areas.

• The access point supports 802.11b/g/n with 2×2 MIMO technology and wireless throughput up to 300Mbps.

• It supports multiple wireless operation modes including Access Point, Client, Access Point WDS, and Client WDS.

• The DAP-F2300W is designed for in-wall installation, offering a clean and professional appearance suitable for hospitality and office environments.

• It supports 802.3af PoE, web-based configuration, SNMP, AC management, firmware upgrade via browser or AC, and IP31 protection.

• Indoor Wireless N Access Point

• 802.11b/g/n 2.4GHz wireless support

• 2×2 MIMO technology

• Wireless throughput up to 300Mbps

• Internal omnidirectional antenna

• 3dBi antenna gain

• Multiple operation modes

• Access Point mode

• Client mode

• Access Point WDS mode

• Client WDS mode

• Supports Route mode

• Supports Bridge networking

• Wireless multimedia optimization

• Traffic shaping support

• Web-based configuration

• Remote configuration and upgrade management via AC / X-Manager

• SNMP management support

• Firmware update via browser or AC

• 802.3af PoE support

• In-wall mounting design

• IP31 protection rating

• Compact ABS enclosure

• Suitable for hotels, offices, schools, cafes, and indoor wireless coverage projects

• Product Type: Indoor Wireless Access Point

• Model: DAP-F2300W

• Wireless Standard: IEEE 802.11b/g/n

• Wireless Frequency: 2.4GHz

• Operating Frequency: 2412MHz – 2472MHz

• Wireless Speed: Up to 300Mbps

• MIMO: 2×2 MIMO

• Radio Baseband / CPU: QCA9531

• Memory: 64MB DDR

• Flash: 16MB

• Front Interface: 2 × 10/100Mbps auto-negotiation Ethernet ports

• Back Interface: 1 × 10/100Mbps auto-negotiation Ethernet port

• Antenna Type: Internal omnidirectional antenna

• Antenna Gain: 3dBi

• Power Requirement: 48V PoE

• PoE Standard: IEEE 802.3af

• Maximum Power Consumption: < 4W

• Operation Modes: Access Point, Client, Access Point WDS, Client WDS

• Networking Modes: Router / Bridge

• Wireless Security: WPA / WPA2

• SSID Hide: Supported

• MAC / IP Filtering: Supported

• Management: Web-based configuration, AC management, SNMP

• Firmware Upgrade: Browser or AC

• Enclosure Material: ABS

• Installation: In-wall mounting kit

• Protection Rating: IP31

• Dimensions: 86 × 86 × 34 mm

• Weight: 105g

• Working Temperature: 0°C to 45°C

• Storage Temperature: -40°C to 70°C

• 802.11b TX Power: 21dBm ±1.5dB

• 802.11g TX Power: 21dBm ±1.5dB

• 802.11n HT20 TX Power: 21dBm ±1.5dB for MCS0–MCS3

• 802.11n HT20 TX Power: 20dBm ±1.5dB for MCS7

• 802.11n HT40 TX Power: 21dBm ±1.5dB for MCS0–MCS3

• 802.11n HT40 TX Power: 20dBm ±1.5dB for MCS7

• RX Sensitivity 802.11b 11Mbps: -90dBm

• RX Sensitivity 802.11g 6Mbps: -89dBm

• RX Sensitivity 802.11g 24Mbps: -88dBm

• RX Sensitivity 802.11g 54Mbps: -76dBm

• RX Sensitivity 802.11n HT20 MCS0: -90dBm

• RX Sensitivity 802.11n HT20 MCS7: -76dBm

• RX Sensitivity 802.11n HT20 MCS15: -69dBm

• RX Sensitivity 802.11n HT40 MCS0: -89dBm

• RX Sensitivity 802.11n HT40 MCS7: -72dBm

• RX Sensitivity 802.11n HT40 MCS15: -68dBm

• Hotel room wireless coverage

• Office indoor Wi-Fi coverage

• School and classroom wireless networks

• Cafes and small shops

• In-wall access point installations

• Indoor broadband wireless access

• Managed wireless network deployments

• Hospitality Wi-Fi projects

• Compact indoor AP installations

• Areas requiring clean wall-mounted Wi-Fi design

• Recommended for indoor wireless projects that require a compact in-wall access point with PoE support.

• Suitable for hotels, offices, cafes, schools, and guest rooms where clean installation and stable 2.4GHz coverage are required.

• A practical choice for projects using AC / X-Manager centralized management.

• Best used in standard browsing and indoor coverage applications, while higher-density or dual-band environments may require a newer dual-band access point.
